Sprint 680XRi - 0.75KW - 4Q Regen Isolated

Product Code: 17735

Availability:In stock

£389.00 - £412.00
£433.00 £389.00

Available Options


Please Note:
To suit our international customers, all prices are displayed ex-VAT. Taxes will be added at Checkout.

0.75kW Din Rail Mounted DC Drive - Sprint 680XRi 230VAC / 110VAC

Sprint 680XRi 0.75kW

Power Output: 0.75kW | 1HP

Power Input: Single Phase 230VAC

Output Current: 6.8A

Frame Size Dimensions


Weight(kg) Width Height Depth
0.75kg 35mm 105mm 120mm

SL Range



680XRi 0.75kW Onboard

  • Single Phase
  • A large amount of I/O
  • 4 Quadrant Regen Isolated

Sprint 680XRi 0.75kW Features

Overview

Make upgrading your existing control panel easier. Save space in new DC single direction motor control systems. The ultra compact DIN rail mounting package lets you install quickly. Three options are available for controlling DC motors up to 12.2 Amps. You can use this versatile range of non-isolated controllers for permanent magnet, shunt wound motors or universal motors. To make your installation quick and simple, all 340XRi, 680XRi, and 1220XRi series controllers have easy to access drive adjustments, plug-on screw terminals and a small foot print from just 70mm x 105mm.

Why Choose a Sprint 680XRi DC Drive?

This ultra compact, fully isolated dc drive has multiple features to make dc motor control easier than ever before. Some features of the Sprint 680XRi include:

  • DIN rail mounting
  • Small footprint
  • Plug-on screw terminals
  • Selectable dual voltage AC supply
Diagram

SprintSL

Energy Efficient

Energy efficiency is a priority when fitting a drive, no matter what the application, an efficient dc drive can make all the difference, with the 680XRi drive, you are guaranteed to get the highest level of efficiency.

Sprint SL Keypad

Standard Features

  • Switch selectable tach or armature voltage feedback.
  • Adjustable IR compensation for improved AVF speed regulation.
  • Compact dimensions make installation and retrofitting a simple task.
  • Terminals include: +10V ref, Min speed, Ramped Input+. Output +/-, Input +/-. Pushbutton +/-, Run input, Tach Input.
Reliable Inverter

Compact & Reliable

The 680XRi drive has been designed in such a way to reduce cost and size so users can benefit from these dc drives without any drawbacks. The 680XRi drive excels with regards to its compact size, due to this feature, it can fit where other drives of the same specification would not, the 680XRi is also easily integrated for trouble-free installation when retrofitting.
