230VAC Single Phase Motors

Single Phase Motors (1Ph) are popular in domestic applications. ACDC Drives hold a large stock of these motors in both Permanent and Dual Capacitor format. To help decide which motor you need, please see the useful information below.

All of these motors are able to switch between clockwise and counter-clockwise operation instantly and speed is variable (will not work with any Inverter). There are several possibilities for mounting these motors to your equipment making this the ideal choice when assembling an adjustment mechanism.

Permanent Capacitor

230VAC Permanent Capacitor Motors

Single Phase AC Permanent Capacitor (0.18kW to 2.2kW) IEC standard electric motors are suitable for industrial equipment and domestic applications with a single phase 220/240V supply. Permanent capacitor (PSC) single phase motors should not be used in hard to start applications such as woodworking machinery, air compressors, high-pressure water pumps, and vacuumed pumps. These motors are ideal for fans, blowers with low starting torque needs, and intermittent cycling uses such as adjusting mechanisms, gate operators and garage door openers, many of which also need instant reversing.



permanent cap motor

Key Advantages of Permanent Cap Motors

Key advantages single phase permanent capacitor motors offer:

  • Speed Controllable (with Variac not an AC Drive)
  • Very reliable
  • Torque Rated
  • 6 pole and 8 pole on request
  • No mechanical starting mechanism
  • Rotatable top mounted aluminum terminal box (capacitor enclosed)
  • Lightweight Multi mount B3, B5, and B14 options
  • Low starting currents




Specifications

  • IEC Standard Dimensions
  • 220 - 240VAC
  • IP55 suited for wet and dusty environments
  • Class F Insulation (40 degrees ambient)
  • S1 Continuous Duty Cycle
  • Multi Mount

Permanent cap electric motors have many domestic applications as well as industrial uses. They are ideally suited for use in fans, blowers, gate operators and garage door operators.


garage door opener

Capacitor Start / Capacitor Run

230VAC Dual Capacitor Motors

Capacitor Start / Capacitor Run (TDA) single phase electric motors are able to handle applications that are too demanding for any other type of single phase electric motor. High starting performance ensures the TEC ML Capacitor Start / Capacitor Run is suitable for agricultural, high pressure washers, vacuum pumps, conveyers, and refrigeration equipment which demand higher starting torque.

permanent cap motor

Key Advantages of Dual Capacitor Motors

Key advantages single phase permanent capacitor motors offer:

  • High starting torque performance 1.8 - 2.5
  • High overload rating
  • Multi mount
  • Light weight aluminum frame
  • Cool running to comparable kW powers
  • Clockwise and Anti clockwise with change of connection
  • Rotatable Aluminum terminal box



Cap Start/Cap Run or Dual Cap Motors provide a higher starting torque than the Permanent Capacitor motors. This enables them to be used in agricultural machinery as well as pressure washers, vacuum pumps and refrigeration.

compressor
