Parker AC10 IP66 0.75kW 1 Phase 230v Inverter

Ã‚

The 0.20kW Parker IP66 AC10 variable speed drive (VSD) is a simple, reliable and economical solution to every-day motor control applications requiring speed or torque control within the power range of 0.25 HP to 250 HP.

Ã‚

AC10 IP66 offers speed or torque control within the power range of 0.4 kW to 15 kW. Having features normally only associated with higher specification drives, including; IP66 protective enclosure, sensorless vector mode, output frequency up to 590 Hz and 3 phase 400 volt supplies in all 5 frame sizes, AC10 IP66 provides an optimised solution for OEM machine builders looking for a compact, cost-effective IP66 drive without compromising on performance.

Why Choose a Parker AC10 IP66 Inverter Drive?

The AC10 IP66 AC Drive is a reliable drive where protection against dust and moisture and needed, it has the capability to resist specific environmental conditions. IP66 protection represents dust tight performance as well as the ability to withstand powerful water jets from all directions. Parker AC10 IP66 offers all the benefits from the AC10 series but with extra protection against the harsh elements.

What Is Ingress Protection (IP)?

IP rating is also known as Ingress Protection, these standards are used to define the level of protection that certain item gets from elements such as water, dust and dirt.

The rating is identified by the letters IP followed by two numbers; the first number stands for the level of protection from solids such as dust and dirt, the second number stands for the degree of protection against water. There are 6 digits for the first set of numbers, and 8 digits for the second.

Details

Drive Layout

Ã‚

Compact - The drive is packaged into a very compact unit, making it simple to mount in an existing panel.
Well Designed - Bottom entry terminals make wiring it up a breeze, and when combined with the front mounted keypad, getting started could not be easier.

Frame Size 1 Dimensions

Ã‚

Weight(kg)	Width	Height	Depth
8.0kg	200mm	412mm	198mm

Simplicity

The Parker IP66 AC10 0.20kW Single Phase Inverter is designed to reduce the time and effort required to install, setup and commission through its easy to use integrated keypad. Minimal wiring requirements and two easily accessed terminal rails make AC10 fast and simple to install, having you up and running in no time at all. Auto-tuning sensorless vector mode takes AC10 beyond simple V/Hz control allowing users requiring greater dynamic speed or torque control for their application to benefit from the drives enhanced 0.5 % speed and 5 % torque accuracy.

Ã‚

Reliability

Proven technology and manufacturing techniques ensure AC10 has been engineered and built to deliver consistently outstanding levels of performance day in, day out ensuring maximum uptime and productivity. Thanks to its conformally coated PCBs, AC10 is able to withstand even the most arduous class 3C3 environment which many other drives in this class would struggle with, allowing you to operate AC10 with the utmost confidence in more applications.

Ã‚

Common Questions

Will this drive run from 230v Single Phase?

Yes, it will run from a single phase 230v supply.

Does that mean it will power a Single Phase motor?

No, the Inverter will only work with a 3 Phase motor, in Delta configuration.

How do I configure the motor in Delta?

See the images to on the right (below ifÃ‚ viewingÃ‚ on a mobile device.

Will the Inverter provide speed control?

Yes, it is set up as standard to provide speed control from the up and down arrows on the keypad. It canÃ‚ also be configured to use a Potentiometer. IfÃ‚ you require stop, start, forward, reverse and a Pot, please see our Control Kits.

What is the difference between 'Filtered' and 'Unfiltered'?

The filtered drive will prevent mains spikes from affecting the drive. If you are using this in a non industrial environment where no external protection will be used, we recommend using the filtered variant.

Ã‚

Need Assistance Working Out Which Drive You Require?

If you need specialist components or just a hand to work out which drive would suit what you need then give us a call on 01905 887 667. Our staff are available during office hours and will be happy to help you with any questions.

Ã‚

Ã‚

AC10 useful downloads

	AC10 Catalog
	AC10 Quickstart
	Product Manual
