Sprint 370E - Ultra Compact Enclosed DC Motor Control 230V / 110V
0.50kW Enclosed DC Drive - Model 370E - 3.7 Amps (0.50KW/60Hz) - Manufacturers Part Number: 370E
Dynamic & Advanced
The DC Drives with Enclosures provide a more advanced 1Q control option for motors rated up to 3.7Amps output current 0.50kW motor power. The 370E DC Drive enclosure is available with 110-240VAC input as standard (and an optional 30-60VAC low voltage option providing 24 – 48VDC output). Models include:- IP40 protection, mains on/off switch, dual voltage supply, fully fused, zero speed interlocked reversing(ER only), dynamic braking (ER Only), set speed potentiometer with graduated scale.
Specifications at a glance:
Adjustable IR compensation for improved AVF speed regulation
Sophisticated dual loop control
Set speed potentiometer with graduated scale
Electronic soft start Drive run input
Suitable for permanent magnet, shunt wound or universal motors
Selectable dual international voltage supply 110/240V AC 50/60HZ
Adjustable current overload protection
Tachogenerator or armature voltage speed feedback Adjustable acceleration rate between 1 and 20 seconds On/Off AC supply
illuminated rocker switch
Terminals:
Simple, reliable and compact. Make controlling DC motors easier with adjustable parameters including: minimum and maximum motor speed, armature current, up ramp and IR compensation.
Low voltage 30/60V AC supply version available for 24/48V DC motors
