37kW - 90kW - 380-500v Parker 890SD Standalone VSD
37kW - 90kW - 380-500v Parker 890SD Standalone VSD
Product Code: 31157
Delayed
NB: Please allow for manufacturer lead time, contact us to confirm availability.
£4,345.60 - £10,464.49
£9,232.95
Next Working Day Delivery* Please allow an extra working day for Scottish Highlands, Northern Ireland, Channel Islands and Isle of Man (Carriage may be extra for these areas).
Please Note:
To suit our international customers, all prices are displayed ex-VAT. Taxes will be added at Checkout.
Have a question?
NB: Please allow for manufacturer lead time, contact us to confirm availability.
415v 890SD Standalone Drive 37kW - 90kW
Select options to suit your application
The 890 SD
AC890SD standalone drives are independent modules with integrated three-phase supply inputs. With a wide range of sizes available, the AC890SD is suitable for every type of application from a small machine to a large industrial high power process line (eg. rolling mill). It is also ideally suited to sectional control such as that found in printing systems.
Download Manual Here
The manual can be downloaded here: AC890 Modular Systems Manual
Accessories and Options
NEW Format for 890 Drives
All 890's will now be shipped as bare Drives, no factory fitted modules or options will be available, you will need to order these and fit in whichever format you require before using your drive.
Modules and Accessories
If you require any Communications Modules or I/O Modules please add these to your basket seperately.
Specification
Technical Specifications - 890SD Standalone Variable Speed Drive 490v 37kW - 90kWElectrical Characteristics
| Operating Temperature | 0 ºC to +45 ºC |
|---|---|
| Storage Temperature | -25 ºC to +55 ºC |
| Enclosure Rating |
IP20 - UL (c-UL) Open Type (North America/Canada) Type 1 Suitable for cubicle mount only |
| Cubicle Installation |
The 890 must be installed to EN60204 Standard in the cubicle. For USA, the cubicle shall meet the requirements of UL50. |
| Humidity | Maximum 85% relative humidity at 40 Degrees C non-condensing |
| Vibration |
The product has been tested to the following specification: Test Fc of EN60068-2-6 10 Hz<=f<=57 Hz sinusoidal 0.075 mm amplitude 57 Hz<=f<=150 Hz sinusoidal 1 g 10 sweep cycles per axis on each of three mutually perpendicular axis |
| Atmosphere | Non Flammable, non corrosive and dust free |
| EMC Compatibility | CE Marked in accordance with 2004/108/EC |
Dimensions
Size and Weight of 890
