30kW Motor 4P 415V-690V IE3 200 Frame - Cast Iron - TEC - B3

Product Code: 17367

Availability:In stock

£875.33

Please Note:
To suit our international customers, all prices are displayed ex-VAT. Taxes will be added at Checkout.

TEC Motor 30kW - 4 Pole | 200 Frame | B3 Mount | 415V / 690V | 3Ph Supply | IE3 Efficiency | Cast Iron Frame


Motor-Cast-iron-Frame-Icon
Motor-B3-Cast-Icon
Motor-Cast-Voltage-Icon
Motor-RPM-Icon

Motor-Cast-Iron-Frame-Icon
Motor-IE3-Icon
Motor-Inverter-Icon
Motor-ShaftSizes-Icon

Motor Specifications

  • 3 Phase 30kW 4 Pole Cast Iron Motor
  • Mount Type: B3 / Foot
  • Rotation Speed: 1470 / 1764
  • IP55, according to IEC 60034-5
  • IE3 High Efficiency
  • Class F Insulation
  • Class B Temperature Rise
  • Continuous duty: S1
  • Torque Output: 194.9Nm
  • Max Current (Delta): 93.6A
  • Max Current (Star): 232.97A
  • Efficiency 100%: 93.6
  • Efficiency 75%: 93.7
  • Bearing DE: 6312 C3
  • Bearing NDE: 6312 C3
  • Cable Glands: 2 x M40 x 1.5
  • Thermal Protection: PTC 140 Degrees C
TEC Logo

Motor Dimensions

These IEC sized Motors have multi-mount terminal boxes resulting in a far greater degree of flexibility and adaptability.

Shaft Diameter (B) Keyway Width (A) Shaft Length (C)
55mm 16mm 110mm

Motor External Dimensions

Weight(kg) Width Height Length
252kg 388mm 497mm 768mm

Motor Options:

30kw 4P Motor With Encoder

Do you require absolute speed control for use in a closed loop application with an inverter? We can supply this motor with a pre installed encoder. Just tick the Box above the 'Add To Cart' button and we will do the rest. If this is urgent and requires a fast turn around, please contact us. Standard fitting time is 7 working days.


Motor With Encoder

30kw 4P Motor With Force Vent (415VAC)

If you require a Forced Vent unit with your motor, click the option above and we will supply the correct unit along with your motor. We recommend these if you plan on running at low speed for longer periods. This will require an extra 415 VAC supply. For details on the actual unit, please see this page: Forced Vent 160 Frame 415 VAC


Forced vent unit
