Power Output: 3.0kW ND / 2.2kW HD | 4HP

Power Input: Single Phase 230VAC

Output Current: 11.0A HD / 12.2A ND

Standard Configuration: EMC Filter Included

Optional Configuration: Without EMC Filter (Select Above)

IP Rating: IP20

Ambient Temperature -10 to +50 Degrees

Humidity: 95% RH or less (non-condensing)

Altitiude: Up to 1000m without derating,up to 4000m with derating

Environmental conditions: IEC 60721-3-3, Class 3C2 (chemical gases), Class 3S2 (solid particles)

Virtual input/output: For connection of I/O functions without physical wiring

Programming Instance: Mini-USB on the front cover; digital operator with Bluetooth® (optional)

Functions:

• Open Loop Zero Speed and torque control of permanent magnet motors
• Run Induction, permanent magnet, and synchronous reluctance motors with only one type of drive
• 590Hz output frequency
• High switching frequency for silent motor operation
• Time-saving and hassle free setup of any motor without the need for auto tuning
• Integrated PID controller with sleep function
• Automatic main power loss ride through
• Speed search function for smooth start of coasting motors
• Braking with over magnetisation for fast stop without braking resistors
• Energy saving function
• Automatic restart after failure
• Overvoltage suppression

Frame Size Dimensions
