110kW Inverter 415VAC 3Ph - Commander C200-09402240A

Product Code: 15013


NB: Please allow for manufacturer lead time, contact us to confirm availability.


Next Working Day Delivery* Please allow an extra working day for Scottish Highlands, Northern Ireland, Channel Islands and Isle of Man (Carriage may be extra for these areas).

Please Note:
To suit our international customers, all prices are displayed ex-VAT. Taxes will be added at Checkout.

NB: Please allow for manufacturer lead time, contact us to confirm availability.

Control Techniques Commander C200 110kW 415VAC Input AC Inverter


C200 110kW Installation

Power Output: 110kW | 175HP

Input: Three Phase 415VAC

IEC Fuse Class gR: 315A

IEC60364-5-52 mm2: Input 2 x 95mm (B1) | Output 2 x 120mm (B2)

Frame Size 1 Dimensions


Weight(kg) Width Height Depth
66.5kg 310mm 1108mm 290mm

Commander C

C200 110kW SI I/O

  • 4 x Digital I/O
  • 3 x Analog inputs (default)/Digital Inputs
  • 1 x Digital input
  • 2 x Relays
Commander C

C200 110kW Onboard

  • 3 x Analog I/O
  • 5 x Digital I/O
  • 1 x Relay

Commander Inverter Common Features

  • Commander Drives are amongst the smallest in their class
  • Drives can be fitted side by side to save space

Easy motor pairing and performance control

    • Fixed boost by default for easy set-up

– Multi-motor control

    • V/Hz for advanced performance

- 100% torque available to 1Hz

- Slip compensation

- Square law V/F mode

- Dynamic V/F mode

- Auto tune (stationary and rotating)

    • Open Loop Vector
    • Enhanced Open Loop RFC

- Closed current loop for greater stability

- Auto tuning (stationary and rotating)

Commander C

Commander Option Modules

Profibus Module



Buy Here

Ethercat Module



Buy Here

Ethernet Module



Buy Here

DeviceNet Module



Buy Here

ProfiNet Module



Buy Here

AI-485 Module



Buy Here

C200 App

Diagnostic Tool App

All Commander C200 Drives allow access to a simple diagnostic reading app. This allows for the fast resolution of faults and error code reading. The App also includes wiring diagrams for first time setup with links to comprehensive manuals. Available on IOS Android and Microsoft.


Machine Control Studio

For advanced applications the Machine Control Studio allows for higher end programming and flexibility of the COmmander drive and its onboard PLC. Utilising the onboard PLC saves on cost and also offers far quicker processing speeds than using a drive with an external PLC unit.



Connect is a drive configuration tool for commissioning, optimising and monitoring drive/system performance using windows environments. The Connect tool allows the user to optimise performance of the drive with minimal effort and knowledge.

Need help setting up your C200?

The Commander Series of drives include a QR code on the inside of the front cover which will quickly take you to drive-setup.com. Here you will find online setup manuals and quick start guides in PDF form and video.


Basic Setup Guides For The C200 Inverter

These video tutorials will assist you in getting the drive configured correctly. They offer a basic overview and several helpful tips.

Commander C200 Inverter Basic Wiring

Control Techniques C200 Wiring Guide

Control Techniques C200 Basic Parameter Guide

Not sure what the various parameters do on the Commander C200? Heres a little Video to help
