1.5kW IP66 Inverter 230VAC 1Ph - TECDrive - Switched

Product Code: 122318


Next Working Day Delivery* Please allow an extra working day for Scottish Highlands, Northern Ireland, Channel Islands and Isle of Man (Carriage may be extra for these areas).

Please Note:
To suit our international customers, all prices are displayed ex-VAT. Taxes will be added at Checkout.

1.5kW IP66 AC Input Inverter TECDRIVE 230VAC Single Phase - SWITCHED

IP66 Tec Drive 1.5kW

Power Output: 1.5kW | 2HP

Power Input: Single Phase 230VAC

Output Current: 7A

Switched: Yes

Filter: EMC

IP Rating: IP66

Frame Size Dimensions


Weight(kg) Width Height Depth
3.1kg 161mm 232mm 179mm

TEC Inverter

Onboard Features

  • 3 x Digital I/O
  • 3 x Analog I/O
  • 1 x Relay I/O
  • Modbus RTU and Canopen

TECDrive Features


TECDrive Inverters provide one of the most straightforward setup processes of any Inverter Drive. Directly connect the drive to your power supply and the motor you wish to control, and use the one button macro selection to get started; it’s that simple.

Why Choose a TEC Inverter Drive?

TECDrive Inverters have been designed with only 14 parameters, all of which can be accessed via the keypad on the front of the drive, allowing the user easy access to critical features. The built-in Macros allow an alternative setup method and rapid commissioning. The built-in Macros include Industrial, Fan and Pump modes.


TEC drive Keypad


Internal Category C1 EMC Filter. An internal filter in every TECDrive saves cost and time for installation. (Cat C1 according to EN61800-3:2004).

Inverter Kit

1.5kW IP66 TecDrive Inverter

For information on IP66 protection, please visit this page.

Reliable Inverter

Rapid Commissioning

The Optistick allows for rapid commissioning of multiple drives with the same parameter settings. It enables copying, backup and restores of drive settings. It also allows for Bluetooth interfacing from a PC running Optitools Studio. We also have IP66 Versions of the full TECDrive range available. Please call the office for details and prices.
