0.75kW Inverter 230VAC 1Ph Parker AC10 - 10G-11-0045-BF

Product Code: 18056

Delayed

NB: Please allow for manufacturer lead time, contact us to confirm availability.

£168.35

Qty

Ask about this product

Next Working Day Delivery* Please allow an extra working day for Scottish Highlands, Northern Ireland, Channel Islands and Isle of Man (Carriage may be extra for these areas).

Please Note:
To suit our international customers, all prices are displayed ex-VAT. Taxes will be added at Checkout.

NB: Please allow for manufacturer lead time, contact us to confirm availability.

Parker AC10 0.75kW 230VAC Input AC Inverter

​

AC10 IP20 0.75kW

Power Output: 0.75kW | 1HP

Power Input: Single Phase 230VAC

Input Current:Â 10A

Output Current:Â 4.5A

Input Protection Current:Â 18.1A

Frame Size 1 Dimensions

Â

Weight(kg) Width Height Depth
1.25kg 80mm 138mm 135mm

AC10 Diagram

AC10 0.75kW Onboard

  • 4 x Analog I/O
  • 7 x Digital I/O
  • 1 x Relay
  • Terminals for Modbus

Parker AC10 Features

Reliable

Proven technology and manufacturing techniques ensure AC10 has been engineered and built to deliver consistently outstanding levels of performance day in, day out ensuring maximum uptime and productivity. Thanks to its conformally coated PCBs, AC10 is able to withstand even the most arduous class 3C3 environment which many other drives in this class would struggle with, allowing you to operate AC10 with the utmost confidence in more applications.

Simplicity

The Parker AC10 0.75kW is designed to reduce the time and effort required to install, setup and commission through its easy to use integrated keypad. Minimal wiring requirements and two easily accessed terminal rails make AC10 fast and simple to install, having you up and running in no time at all. Auto-tuning sensorless vector mode takes AC10 beyond simple V/Hz control allowing users requiring greater dynamic speed or torque control for their application to benefit from the drives enhanced 0.5 % speed and 5 % torque accuracy.

AC10 Isometric


AC10 Keypad

Compact

Having compact dimensions and features normally only associated with higher specification drives, including, sensorless vector mode, output frequency up to 590 Hz, 3 phase 480 VAC supplies in all frame sizes and a full 150 % overload at 0.5 Hz for 1 minute, AC10 provides an optimized solution for OEM machine builders looking for a compact, cost-effective, UL listed drive without compromising on performance.

AC10

Available as a Kit

If you require a 3 phase motor and an inverter as a combined kit please check out our control kits These kits combine the AC10 Inverter with a Motor and Control Pendant. These kits offer a pre-wired pendant which can be operated remotely.


Reliable Inverter

Reliably Economical

The 0.75kW Parker AC10 variable speed drive (VSD) is a simple, reliable and economical solution to every-day motor control applications requiring speed or torque control within the power range of 0.25 HP to 250 HP.

​

Common Questions

Will this drive run from 230v Single Phase?

Yes, it will run from a single phase 230v supply.

Does that mean it will power a Single Phase motor?

No, the Inverter will only work with a 3 Phase motor, in Delta configuration.

How do I configure the motor in Delta?

See the images to on the right (below if viewing on a mobile device.

Will the Inverter provide speed control?

Yes, it is set up as standard to provide speed control from the up and down arrows on the keypad. It can also be configured to use a Potentiometer. If you require stop, start, forward, reverse and a Pot, please see our Control Kits.

What is the difference between 'Filtered' and 'Unfiltered'?

The filtered drive will prevent mains spikes from affecting the drive. If you are using this in a non industrial environment where no external protection will be used, we recommend using the filtered variant.

Â

StarDelta

​

AC10 useful downloads

AC10 Catalog
AC10 Quickstart
Product Manual
