11kW Motor 2P 415V-690V IE3 160 Frame - Cast Iron - TEC - B3

TEC Motors

Product Code: 17991

Click here for downloads

£612.11

Qty

Ask about this product

Add to Compare

Next Working Day Delivery* Please allow an extra working day for Scottish Highlands, Northern Ireland, Channel Islands and Isle of Man (Carriage may be extra for these areas).

Please Note:
To suit our international customers, all prices are displayed ex-VAT. Taxes will be added at Checkout.

Description Reviews

TEC Motor 11.0kW - 2 Pole | 160 Frame | B3 Mount | 415V / 690V | 3Ph Supply | IE3 Efficiency | Cast Iron Frame

Motor Specifications

3 Phase 11.0kW 2 Pole Cast Iron Motor
Mount Type: B3 / Foot
Rotation Speed: 2930 / 3516
IP55, according to IEC 60034-5
IE3 High Efficiency
Class F Insulation
Class B Temperature Rise
Continuous duty: S1
Torque Output:35.85Nm
Max Current (Delta):19.34A
Max Current (Star):11.17A
Efficiency 100%:91.2
Efficiency 75%:93.8
Bearing DE: 6309 C3
Bearing NDE: 6309 C3
Cable Glands: 2x M32 x 1.5
Thermal Protection: PTC 140 Degrees C

Motor Dimensions

These IEC sized Motors have multi-mount terminal boxes resulting in a far greater degree of flexibility and adaptability.

Shaft Diameter (B)	Keyway Width (A)	Shaft Length (C)
42mm	12mm	110mm

Motor External Dimensions

Weight(kg)	Width	Height	Length
118kg	290mm	384mm	640mm

Downloads

Motor Options:

11kw 2P Motor With Encoder

Do you require absolute speed control for use in a closed loop application with an inverter? We can supply this motor with a pre installed encoder. Just tick the Box above the 'Add To Cart' button and we will do the rest. If this is urgent and requires a fast turn around, please contact us. Standard fitting time is 7 working days.

11kw 2P Motor With Force Vent (415VAC)

If you require a Forced Vent unit with your motor, click the option above and we will supply the correct unit along with your motor. We recommend these if you plan on running at low speed for longer periods. This will require an extra 415 VAC supply. For details on the actual unit, please see this page: Forced Vent 160 Frame 415 VAC
