FCNDK Worm Gearboxes

TCNDK25 Gearbox
TCNDK25 Gearbox

TEC Motors

£60.30

TCNDK30 Gearbox
TCNDK30 Gearbox

TEC Motors

from £60.30

TCNDK40 Gearbox
TCNDK40 Gearbox

TEC Motors

from £70.70

TCNDK50 Gearbox
TCNDK50 Gearbox

TEC Motors

from £100.20

TCNDK63 Gearbox
TCNDK63 Gearbox

TEC Motors

£125.36

TCNDK75 Gearbox
TCNDK75 Gearbox

TEC Motors

£171.25

TCNDK90 Gearbox
TCNDK90 Gearbox

TEC Motors

£250.81

TCNDK110 Gearbox
TCNDK110 Gearbox

TEC Motors

from £361.62

TCNDK130 Gearbox
TCNDK130 Gearbox

TEC Motors

£505.03

FCNDK25 Single Output Shaft FCNDK25 Single Output Shaft
TCNDK25 Single Output shaft

TEC Motors

£6.98

FCNDK25 Double Output Shaft FCNDK25 Double Output Shaft
TCNDK25 Double Output shaft

TEC Motors

£8.20

FCNDK30 Single Output Shaft FCNDK30 Single Output Shaft
TCNDK30 Single Output shaft

TEC Motors

£6.98

FCNDK30 Double Output Shaft FCNDK30 Double Output Shaft
TCNDK30 Double Output shaft

TEC Motors

£8.20

FCNDK40 Single Output Shaft FCNDK40 Single Output Shaft
TCNDK40 Single Output shaft

TEC Motors

£10.43

FCNDK40 Double Output Shaft FCNDK40 Double Output Shaft
TCNDK40 Double Output shaft

TEC Motors

£10.21

FCNDK50 Single Output Shaft FCNDK50 Single Output Shaft
TCNDK50 Single Output shaft

TEC Motors

£10.76

FCNDK50 Double Output Shaft FCNDK50 Double Output Shaft
TCNDK50 Double Output shaft

TEC Motors

£12.24

FCNDK63 Single Output Shaft FCNDK63 Single Output Shaft
TCNDK63 Single Output shaft

TEC Motors

£12.04

FCNDK63 Double Output Shaft FCNDK63 Double Output Shaft
TCNDK63 Double Output shaft

TEC Motors

£14.28

FCNDK75 Single Output Shaft FCNDK75 Single Output Shaft
TCNDK75 Single Output shaft

TEC Motors

£14.32

FCNDK75 Double Output Shaft FCNDK75 Double Output Shaft
TCNDK75 Double Output shaft

TEC Motors

£16.35

FCNDK90 Single Output Shaft FCNDK90 Single Output Shaft
TCNDK90 Single Output shaft

TEC Motors

£23.20

FCNDK90 Double Output Shaft FCNDK90 Double Output Shaft
TCNDK90 Double Output shaft

TEC Motors

£27.63

FCNDK110 Single Output Shaft FCNDK110 Single Output Shaft
TCNDK110 Single Output shaft

TEC Motors

£31.96

TEC - TCNDK Worm Gearboxes

These units have been designed based on the modular format system. All types of IEC motors can be fitted. They are heavily customisable. All sizes in this range, apart from size 150, are supplied filled with synthetic long-life oil grade ISO VG 320. Housings for sizes 25-90 are aluminium, sizes 110-150 are cast iron.

Due to the number of options available, we understand that assistance may be required in sourcing the correct part. Please call us if you require on 01905 887 667, and we will be more than happy to help.

TCNDK Motor Gearbox Combinations

We can supply Motor Gearboxes prebuilt to suit almost any application. If you require an TCNDK Gearbox with a motor fitted, and specific output speed, please contact us using the 'Send Us An Email' link, or call the sales office on 01905 887 677.


Motor Gearbox

TCNDK Dimensions

Each individual product listing contains the dimensional info pertaining to that gearbox. Please click in the item, and see the images, or scroll down to the downloads section to view the technical pdf.

Motor Gearbox Dimensions

What sizes and Ratios are available?

TCNDK gearboxes are available in the following ratios:


TCNDK Gearbox (Worm Gear)
TCNDK25 7.5:1 - 50:1
TCNDK30
 7.5:1 - 80:1
TCNDK40
 7.5:1 -100:1
TCNDK50
 7.5:1 -100:1
TCNDK63
 7.5:1 -100:1
TCNDK75
 7.5:1 -100:1
TCNDK90
 7.5:1 -100:1
TCNDK110
 7.5:1 -100:1
TCNDK130
 7.5:1 -100:1
TCNDK150
 7.5:1 -100:1

If these ratios do not suit your application, we can also supply Pre Stage gearboxes, which will effectively act as a multiplier for the gearbox and increase the number of ratios available.

TCNDK Gearbox Accessories

We can supply a full range of accessories for the TCNDK range, these include:

Gearbox TCNDK Accessories



  • Torque Arm
  • Output flanges for IEC compatible motors
  • Single or Double Output Shafts
  • Output shaft reducing sleeves
  • Combination Kits
  • Pre-Stage Kits




Why Buy TCNDK from ACDC Drives?

We use TCNDK gearboxes in our systems daily, our product knowledge is first hand. If you require any help with Right Angled Gearboxes call our sales team today by phone on 01905 887 667.
