Sprint 1200E - Ultra Compact Enclosed DC Motor Control 230VAC / 110VAC
1.8kW Enclosed DC Drive - Model 1200E - 12 Amps (1.8KW/60Hz) - Manufacturers Part Number: 1200E
Dynamic & Advanced
The DC Drives with Enclosures provide a more advanced 1Q control option for motors rated up to 12 Amps output current 1.8kW motor power. The 1200E DC Drive enclosure is available with 110-240VAC input as standard (and an optional 30-60VAC low voltage option providing 24 – 48VDC output). Models include- IP40 protection, mains on/off switch, dual voltage supply, fully fused, zero speed interlocked reversing(ER only), dynamic braking (ER Only), set speed potentiometer with graduated scale.
Specifications at a glance:
- Adjustable IR compensation for improved AVF speed regulation
- Sophisticated dual-loop control
- Set speed potentiometer with graduated scale
- Electronic soft start Drive run input
- Suitable for permanent magnet, shunt-wound or universal motors
Adjustable
- Minimum Motor Speed
- Maximun Motor Speed
- Armature Current
- Acceleration Rate
- IR Compensation
Technical highlights:
- For DC motors rated up to 8 Amps
- Integral AC supply fuse
- Selectable dual international voltage supply 110/240V AC 50/60HZ
- Adjustable current overload protection
- Tachogenerator or armature voltage speed feedback Adjustable acceleration rate between 1 and 20 seconds On/Off AC supply
- illuminated rocker switch
Terminals:
Simple, reliable and compact. Make controlling DC motors easier with adjustable parameters including minimum and maximum motor speed, armature current, up ramp and IR compensation.
