TEC Brake Motor 7.5kW - DC Brake 2 Pole
| Output | 7.5 |
| Rated Current | 13.81 | 7.97 |
| Rotation Speed | 2910 | 3492 |
| Efficiency 100 | 88.1 |
| Efficiency 75 | 88.3 |
| Efficiency 50 | 87.1 |
| Power Factor | 0.89 |
| Rated Torque | 24.61 |
| Tst Tn Times | 3.5 |
| Tmin Tn Times | 1.9 |
| Tmax Tn Times | 3.7 |
| Ist In Times | 9.5 |
| Noise | 80 |
| Net Weight | 46.2 |
| Moment Of Inertia | 0.014635 |
| Full Frame Ref | 132S2-2 |
| Frame Size | 132 |
| Construction | Aluminium Brake Motor |
| Mounting | Select
|
| Mounting Type | Select
|
| Type Of Feet | Removable feet |
| Insulation Class | F |
| Efficiency Level | BRAKE |
| Bearings Brand | NSK |
| Bearing Type 1 | 6308 2RS C3 |
| Bearing Type 2 | 6208 2RS C3 |
| Lifetime Of Bearings | 20000 |
| Allowed Radial Load | 1809 |
| Allowed Axial Load | 1414 |
| Phase | Three Phase |
| Pole | 2 |
| Series | MSB |
| Brake Nm | 60 |
| Brake Voltage | 178v DC |
| Rectifier | Half Wave |
