TEC Brake Motor 5.5kW -Â DC Brake 4 Pole
| Output | 5.5 |
| Rated Current | 11.04 | 6.37 |
| Rotation Speed | 1450 | 1740 |
| Efficiency 100 | 87.7 |
| Efficiency 75 | 88.3 |
| Efficiency 50 | 87.3 |
| Power Factor | 0.82 |
| Rated Torque | 36.22 |
| Tst Tn Times | 2.6 |
| Tmin Tn Times | 2.2 |
| Tmax Tn Times | 3.4 |
| Ist In Times | 8.7 |
| Noise | 71 |
| Net Weight | 43 |
| Moment Of Inertia | 0.027736 |
| Full Frame Ref | 132S-4 |
| Frame Size | 132 |
| Construction | Aluminium Brake Motor |
| Mounting | Select
|
| Mounting Type | Select
|
| Type Of Feet | Removable feet |
| Insulation Class | F |
| Efficiency Level | BRAKE |
| Bearings Brand | NSK |
| Bearing Type 1 | 6308 2RS C3 |
| Bearing Type 2 | 6208 2RS C3 |
| Lifetime Of Bearings | 20000 |
| Allowed Radial Load | 2275 |
| Allowed Axial Load | 1913 |
| Phase | Three Phase |
| Pole | 4 |
| Series | MSB |
| Brake Nm | 70 |
| Brake Voltage | 178v DC |
| Rectifier | Half Wave |
